Input Voltage: AC110V-240V/50-60Hz
Light Source Specifications: 400W white LED module
Color Temperature: 8000k
Color Rendering Index: 75
Light Source Lifespan: 50,000 hours
Illuminance: 80,000 LUX at 4 meters
Rated Power: 500W
Channel Modes: 22 and 26 channels
Dimmer System: 0-100% linear adjustment
Focus System: Linear adjustment from 4 to 50 meters
Atomization System: 1 independent atomization effect, soft and natural light spot
Zoom Angle: 4-35 degrees
High-Speed Strobe: 0-30 flashes/second, adjustable strobe effect - strobe macro function
Color: 12 colors + white light, color half-tone function
Color System: Independent CMY + CTO color mixing system
Fixed Pixels: 12 fixed patterns + white light
Rotating Patterns: 7 glass patterns, each with independent forward and reverse rotation
Prism System: Standard with a single 8-row calibration mirror and 8 prisms, each with independent forward and reverse rotation, with stackable functions
Macro Functions: Console reset, auto-propelled mode, master-slave mode
Display: LCD, keypad + touch dual operation modes
Control Signal: International standard DMX512. With RDM function, online software upgrades and address code swapping
Cooling: Enhanced cooling with an axial fan
Safety Device: Electronic temperature control with overheat protection, automatically shuts off in the event of a system failure
Pan/Tilt: The waterproof lamp features 540° pan or 270° tilt scanning, with fast and stable speed. The lamp is equipped with an intelligent photoelectric reset correction system, automatically returning to its original position in the event of an accidental misoperation. Additionally, it features pan and tilt locks for easier maintenance and transport. Cooling System:
Utilizing CFD software to analyze the lamp's heat flow, a low-noise cooling system was designed.
The fan drive provides excellent performance and extremely low noise.
Waterproof rating: IP65
Net weight: 27 kg
Dimensions: 424 x 367 x 725 mm
Gross weight: 33.28 kg
Packaging dimensions: 601 x 530 x 735 mm
Double flight case dimensions: 92 x 47 x 90 cm
Weight: 93 kg
Appearance: The lamp is constructed of high-strength engineering nylon plastic with UV-resistant treatment for high-temperature and aging resistance, and a high-temperature, die-cast aluminum housing. The lightweight design features airflow guidance and intelligent temperature monitoring for rapid heat dissipation.
